ZUAZO   S.A.

Miñano Mayor

Alava – Spain

BSG ZUAZO has been involved for more than 50 years in mechanical components manufacturing and working for the continuous updating in machinery, staff training and manufacturing technologies.

Nowadays we are offering our engineering and experience to produce and deliver your solutions for customized high precision ground ball screws and spiral bevel gears, meeting the flexibility and reliability that your company demands for the most precise requirements.

BSG-ZUAZO Leading your precision.

Designing and manufacturing:

1.-High precision ground ball screws:

*   Precision: ISO1, ISO3, ISO5 according to UNE-ISO 3408

*   From Ø20 mm up to Ø300 mm

*   Maximum length in 1 piece 16 meters

*   Precision: ISO1, ISO3, ISO5 according to UNE-ISO 3408

*   Ground precision ball screws

*   Complete design and manufacturing for rotating nut assemblies

*   High load applications  & High speed solutions.

2.-Precision spiral bevel gears:

-HPG-Spiral Bevel Gear cutting:Ø Maximum: 2200 mm. Guaranteed quality: 6-DIN 3962

-Spiral Bevel Gear Grinding:Ø Maximum: 850 mmNormal Modul (Mn) Maximum: 16. Guaranteed quality: 4-DIN 3962

-Spiral Bevel Gear Lapping:Ø Maximum: 650 mmNormal Modul (Mn) Maximum: 12. Guaranteed quality: 8-DIN 3962

MYL   S.A.

Mendaro – Guipuzkoa

Spain

In 1969 Manuel Gil Cengoitia, driven by an unstoppable spirit of enterprise, founded Talleres MYL and embarked on his career on just 200 m2 of premises in Elgoibar, designing, making and repairing spindles for machine tools. He set up a flexible family business committed to closeness to its customers and an end product of excellent quality. MYL today is founded on this same attitude, in the conviction that this is the best and only way to meet the needs of those who depend on our work. Today, run by the second generation of the family on our 1,500 m2 of premises in Mendaro, and with a much more structured organization, we are committed to innovation, knowledge management and B2B partnership in order to meet the needs of a much more competitive, global market. This philosophy is strengthened by the creation of work groups who combine experience with a strong orientation towards innovation to promote new, better technological progress that enables us to take on the demanding projects of the future.

We are convinced that commitment to our customers, teamwork and an ongoing commitment to technology are the key to confronting the new challenges of a highly demanding global market.

EXPERIENCE: The experience accumulated over more than 45 years of existence has enabled us to build up an inestimable database and valuable knowledge of the product and market. If we do not have the design the customer is looking for, we know or will find the place to start.
QUALITY: Quality must be seen, touched and felt, therefore each one of the manufacturing and repair process stages is very carefully controlled and available on an extranet that we share with our customers.
NEAR-AT-HAND: To be able to speak to, interact with and directly contact our customers is, for us, a luxury and a necessity. As only in this way will we get to know their real needs, treating every model with the devotion and level of detailed care that it deserves.
DESIGN & RETROFITTING: Thanks to the use of our own technologies and engineering, we are capable of manufacturing and retrofitting special spindles adapted to customer needs.
TRACEABILITY: From the arrival of the spindle at the factory, to its identification, dismantling, cleaning, testing and assembly and final repair. Each and every one of the steps is strictly controlled, identified and monitored by our team of professionals.
3D DESIGN: Each and every one of the designs on which we work is prepared in 3D by a specialized team and expert.
CUSTOMISATION: We customize and adapt any design that our customers require. Our technological capability and flexibility allows us to design a new spindle or retrofit following the technical specifications of the customer.
FLEXIBILITY: To be able to respond to the needs of our customers, whoever they are, and taking painstaking care of each one of the stages is our greatest satisfaction.

OUR PRODUCTS: We manufacture and adapt any spindle on the market

ID GRINDING
Mechanical transmission: Belt driven spindles for grinding internal diameters. Grinding from 2 mm diameter and lengths of up to 2000 mm. Air-oil or permanent grease lubrication.
Motor transmission: High frequency motor driven spindles for grinding internal diameters. Synchronous and asynchronous integrated motors. Water or forced ventilation and cooling. Powers from 0.75 kW and working speeds of up to 120,000 rpm. Can be supplied with air-oil lubrication unit and frequency inverter.

OD GRINDING
Mechanical transmission: Belt driven spindles for grinding external diameters. Incorporation of a radial force compensation system to prevent pulling of the belt. Options to add dynamic wheel balancing systems.
Motor transmission: High frequency motor driven spindles for grinding external diameters. Synchronous and asynchronous integrated motors. Water or forced ventilation cooling. Powers from 0.75 kW to 100 kW. Can be supplied with lubrication unit and frequency inverter. Automatic wheel change and dynamic balancing systems option.

HYDROSTATIC EXTERNAL GRINDING
Mechanical transmission: Belt driven hydrostatic spindles for grinding internal diameters. Special pulleys with belt pull radial force compensation system. Bodies with clamps, wheel couplings and oil connectors in accordance with customer requirements. Can be supplied together with the hydraulic unit.
Motor transmission: High frequency motor driven hydrostatic spindles for grinding external diameters. Max 6000 rpm for grinding with CBN grinding wheels. Dynamic balancing systems. Bodies with clamps, wheel couplings and oil connectors in accordance with customer requirements.

CUSTOMIZED: Special spindles according to customer needs. Drive spindle for grinding. Grinding electro-spindle for gantry milling machine. External grinding units for rubber and polyurethane. Grinding spindles for vertical lathes with automatic spindle changing. External and internal grinding units for horizontal lathes. Wheel diamond dressers. Internal grinding units adapted to a CNC turning machine. Applications for frighten welding.

TOOL POST GRINDERS: The MYL tool post grinders equipped with the renowned MYL grinding spindles are regularly used on lathes for external and internal grinding and front faces, as well as on planing machines and others.

MILLING: Belt or direct motor driven milling spindles. ER, SK, HSK and special clamping systems. Grease and air-oil lubrication. Option to install accelerometers and temperature sensors for the bearings.
